Vehicle Specifications

Engine

SpecificationValue
Engine Displacement102 CC
Engine TypeAir cooled, 4 stroke
Number Of Cylinders1
Valves Per Cylinder2
Max Power8.2 PS @7500 rpm
Max Torque8.6 Nm @5000 rpm
Bore x Stroke48 x 58.8 mm
Fuel TypePetrol
StarterElectric-Kick

Transmission

SpecificationValue
Transmission TypeManual
Number Of Speed Gears4
Final Drive (Rear Wheel)Chain

WHEELS & TYRES

SpecificationValue
Front Tyre 2.75 X 17", 41 P
Rear Tyre 3.00 X 17", 50 P

BRAKES

SpecificationValue
Front Brake Type110 mm Drum
Rear Brake Type110 mm Drum

SUSPENSION

SpecificationValue
Suspension FrontHydraulic, Telescopic Type, 125mm travel
Suspension RearSNS, Trailing arm with co- axial hydraulic shockabsorber and coil springs

DIMENSIONS

SpecificationValue
Overall Length2000 mm
Overall Width840 mm
Overall Height1060 mm
Wheelbase1255 mm
Ground Clearance190 mm
Kerb Weight108 kg
Fuel Capacity11.5 Litres
